App lication range
Generator set
Compressor set
Construction machinery
Agriclltural machinery
Products Overview
| 型号 Model | 缸径/行程 Bore/stroke (mm) | 排量 Displacement (L) | 功率/转速 power/ rotating speed (kw/rpm) | 尺寸 Dimension(cm) | 重量 Weight(kg) | |||
| F2L912 | 100/120 | 1.88 | 14/1500 | 17/1800 | 20/2300 | 68*70*88cm | 260kg | |
| F3L912 | 100/120 | 2.828 | 24/1500 | 29/1800 | 36/2300 | 38/2500 | 94*82*102cm | 375kg |
| F4L912 | 100/120 | 3.77 | 32/1500 | 38/1800 | 46/2300 | 51/2500 | 107*82*102cm | 425kg |
| F6L912 | 100/120 | 5.655 | 48/1500 | 60/1800 | 74/2300 | 78/2500 | 128*83*106cm | 550kg |
| F4L912T | 100/120 | 3.77 | 41/1500 | 48/1800 | 52/2000 | 107*82*102cm | 450kg | |
| F6L912T | 100/120 | 5.655 | 61/1500 | 72/1800 | 81/2300 | 85/2500 | 128*83*106cm | 580kg |
| F6L913 | 102/125 | 6.128 | 51/1500 | 65/1800 | 79/2300 | 85/2500 | 128*83*108cm | 565kg |
| BF4L913 | 102/125 | 4.086 | 47/1500 | 55/1800 | 66/2300 | 78/2500 | 107*83*108cm | 470kg |
| BF6L913 | 102/125 | 6.128 | 74/1500 | 88/1800 | 112/2300 | 118/2500 | 141*85*113cm | 600kg |
| BF6L913C | 102/125 | 6.128 | 84/1500 | 105/1800 | 125/2300 | 141/2500 | 141*85*120cm | 620kg |
| F3L912W | 100/120 | 2.828 | 29/2150 | 31/2300 | 33/2500 | 118*85*106cm | 410kg | |
| F4L912W | 100/120 | 3.77 | 39/2150 | 42/2300 | 44/2500 | 125*85*106cm | 450kg | |
| F6L912W | 100/120 | 5.655 | 60/2150 | 63/2300 | 66/2500 | 160*85*106cm | 610kg | |
Output power curve
Section plane of engine
Drop us an email, let’s discuss more details
